Digital Signal Synchronizer



  • When analog composite video signal multiplexed (or switched) by MATRIX or similar products from multiple CCTV cameras with no GENLOCK function is displayed on monitor, blanking (rolling) caused by un-sychronization of multiplexed video source will be appeared in monitor. Main function of DSS is to minimize these kinds of blanking issues.
  • NYSC, PAL format support
  • 1CH Video Input: 1V peak-to-peak, 75 Ohm, BNC connector
  • 1CH Video Output: 1V peak-to-peak, 75 Ohm, BNC connector
  • Supply Power: DC+5V/1.5A
