| Display Panel |
Screen Size |
17" |
| Aspect Ratio |
4:3 |
| Technology |
TFT LCD |
| Resolution (pixel) |
1280 x 1024 (SXGA) |
| Brightness |
400 cd/m2 |
| Contrast Ratio |
500:1 |
| Response Time |
12 m/s |
| Horizontal View Angle |
160 (+/-80) |
| Vertical View Angle |
140 (+/-70) |
| Colors |
16.2 Millon |
| Input Signal |
Horizontal Frequency |
31-80 KHz |
| Vertical Frequency |
56/78 KHz |
| Audio |
Internal Speaker(1W*2) |
Yes |
| Connections |
PC input (15pin) |
Analog RGB |
| S-Video |
Yes |
| Video Composite IN(BNC) |
Yes |
| Video Composite OUT(BNC) |
Yes |
| Audio IN/OUT(Stereo Jack) |
Yes |
| USB UP(1)/Down(1) |
Optional |
| DVI-D (24pin, Single) |
Optional |
| Controls |
Brightness |
Yes |
| Contrast |
Yes |
| Color |
Yes |
| Sharpness |
Yes |
| Volume |
Yes |
| PIP |
No |
| OSD Languages |
German/Spanish/French/English/Italian |
| Adjustable Angle |
Tilt(Up/Down) |
30 / 5 degree |
| Plug & Play |
DDC 1/2B |
| Product Color |
Black |
| Accessories |
Power Cord |
Yes |
| AC-DC Power Adapter |
Yes (UL, CSA, TUV, GS, etc.) |
| 15pin PC Cable |
Yes |
| Audio Cable(Stereo) |
Yes |
| Audio Cable(Y-Cable) |
Yes |
| BNC Cable (75 Ohm, 1.5m) |
Yes |
| DVI-D (24pin, Single) |
Optional |
| DDC Drive (Diskette) |
Yes |
| User's Manual |
Yes |
| Wall Mount Kits |
Optional |
| Others |
Net Dimensions(WxHxD) |
400 x 180 x 370mm |
| Gross Dimensions(WxHxD) |
490 x 192 x 435mm |
| Net Weight(kg) |
5.5kg |
| Gross Weight(kg) |
6.5kg |
| Stuffying quantity |
520pcs/20' ; 1,040pcs/40' |
| VESA |
100 x 100mm |
| Power Specs |
DC 12V 50W 4.16A |
| Main Voltage |
110-240 VAC/50~60Hz |
| Power consumption(Watt) |
42W(working) |
| Stand-by Power consumption |
< 2 Watt |
| Approvals |
FCC/CE |
|
|
|
 |
|
