| Display Panel |
Screen Size |
20.1" |
| Aspect Ratio |
4:3 |
| Technology |
TFT LCD |
| Resolution (pixel) |
1600 x 1200 (UXGA) |
| Brightness |
250 cd/m2 |
| Contrast Ratio |
400:1 |
| Response Time |
16 m/s |
| Horizontal View Angle |
176 (+/-88) |
| Vertical View Angle |
176 (+/-88) |
| Colors |
16.7 Millon |
| Input Signal |
Horizontal Frequency |
30-81 KHz |
| Vertical Frequency |
56/85 KHz |
| Video |
Signal Input |
Analog RGB |
| Sysc Type |
Seperate |
| PAL/SECAM |
Automatic Scan System |
| Connections |
S-Video |
Yes |
| Video Composite(RCA) |
Yes (BNC adapter is optional) |
| Audio IN R / L (RCA) |
Yes |
| Audio IN/OUT(Stereo Jack) |
Yes |
| PC input (15pin) |
Yes |
| DVI-D (24pin, Single) |
Optional |
| Controls |
Brightness |
Yes |
| Contrast |
Yes |
| Color |
Yes |
| Sharpness |
Yes |
| Volume |
Yes |
| AUTO/Manual Scan |
Yes |
| PIP |
Yes |
| OSD Languages |
7 Language Support |
| Adjustable Angle |
Tilt(Up/Down) |
0 |
| Plug & Play |
DDC 1/2B |
| Product Color |
Metallic Silver |
| Accessories |
Power Cable |
Yes |
| AC-DC Power Adapter |
Yes (UL, CSA, TUV, GS, etc.) |
| 15pin PC Cable |
Yes |
| Audio Cable(Stereo Cable) |
Yes |
| AV Cable(Video/Audio R/L) |
Yes |
| BNC Adapter |
Yes |
| DVI-D (24pin, Single) |
Optional |
| Remote Control |
Optional |
| DDC Drive (Diskette) |
Yes |
| User's Manual |
Yes |
| Wall Mount Kits |
Optional |
| Others |
Net Dimensions(WxHxD) |
485 x 195 x 453mm |
| Gross Dimensions(WxHxD) |
555 x 232 x 505mm |
| Net Weight(kg) |
8.0kg |
| Gross Weight(kg) |
9.0kg |
| Stuffying quantity |
380pcs/20' ; 760pcs/40' |
| VESA |
100 x 100mm |
| Power Specs |
DC 18V 70W 3.88A |
| Main Voltage |
110-240 VAC/50~60Hz |
| Power consumption(Watt) |
54W(working) |
| Stand-by Power consumption |
< 2 Watt |
| Blanking-Free Technology |
Yes |
| Approvals |
FCC/CE |
|
|
|
 |
|
